1600 T3 Portable Diesel Rotary Screw Compressor

Sullair 1600 Tier 3 rotary screw portable air compressor delivers 1600 cfm. Unit is designed for reliability and total accessibility. Powered by a Tier 3 emissions compliant Caterpillar engine. Mounting options are tri-axle, four-wheel steerable and less running gear.  The compressors features a pneumatic inlet valve and 0 to 100% capacity control.

Models vary by region. Please contact your Sullair sales representative for more details.

Jump To:

Specs Contact Us
1600 Portable Air Compressor

Flow

1600 cfm
36.8 m³/min

Pressure

100 psi
7 bar

Power

540 hp
403 kW
  • 0 to 100% capacity control
  • COMPASS® controller
  • Electronic engine control
  • Curbside instrument panel – in weather tight enclosure
  • Protective shutdown switches
  • Two-stage air filters with safety element
  • Ample service doors
  • Containment frame
  • Galvanneal sheet metal
  • AWF® Compressor Fluid - All weather, all climate fluid
  • Warranty
    • 1 year standard warranty
    • 2 year standard air end warranty
    • 5 year or 10,000 hour air end warranty when continuously serviced at the recommended intervals with Sullair AWF compressor fluid and filters
    • Diesel engine warranty applies - contact Sullair for more information

      Features may vary by model, please contact your local distributor for more information

  • Block heater
  • Special color paint
  • Aftercooler and filters / louvers: aftercooler and filters provide instrument quality air that meets ISO 8573-1: Class 1.7.1 Compressed Air Standard
  • Three mounting options
    • Less running gear
    • Four-wheel steerable
    • Tri-axle
      • Electric brakes
      • Mechanical parking brake
      • E-Z lube axle



1600 (T3)

ACTUAL DELIVERY - CFM( M3/MIN)

1600 (45.3)

RATED PRESSURE - PSIG (BAR)

100 (7)

PRESSURE RANGE, MIN - PSIG (BAR)

80 (5.5)

PRESSURE RANGE, MAX - PSIG (BAR)

100 (6.9)

ENGINE MAKE & MODEL

CATC-15ATAAC (T3)

AVAILABLE POWER - BHP (KW)

540 (403)

FUEL TANK CAPACITY -GAL (L)

190 (719)

FUEL CONSUMPTION 100% LOAD - GPH (L/H)

21.7 (82.1)
